stainless steel 304 gas-liquid filter wire mesh/vapor-liquid filter mesh gas liquid filter mesh manufacturer from China Anping RuiLong Metal Product Co.,Itd

stainless steel 304 gas-liquid filter wire mesh/vapor-liquid filter mesh gas liquid filter mesh

Place of Origin:

Hebei, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

pecifications
1.Wire dia.:0.08-0.5mm
2.Mesh width: 10-12000mm
3.Material:SSwire,Gal wire etc
stainless steel 304 gas-liquid filter wire mesh

pecifications

1.Wire dia.:0.08-0.5mm
2.Mesh width: 10-12000mm
3.Material:SSwire,Gal wire etc

stainless steel 304 gas-liquid filter wire mesh/vapor-liquid filter mesh gas liquid filter mesh

Hebei ruilong Metal Products Factory

The material of wire mesh for filtering liquid and gascould be stainless steel wire, copper wire, galvanized iron wire or polyamide. Usually wire mesh for filtering liquid and gas is made of stainless steel 304, 316 or other materials, which is mainly used to filter liquid and gas.

Wire mesh for filtering liquid and gas is a kind of metal wire mesh woven by steel wires. It can separate different kinds of liquids and particles exsiting in the air.
Wire mesh for filtering liquid and gas is the major component to form wire mesh demister, wire mesh mist eliminator and other related seperating equipment.

Wire mesh for filtering liquid and gas is mainly used to clean air and water, seperating the mixtures that exsiting in them. Also it applies in many chemical factories, metal processing factories and some other large-scale public catering

Specification List of Wire Mesh for Filtering Liquid and Gas

Specification List of Wire Mesh for Filtering Liquid and Gas
Model	Specification	Wire Diameter mm	Materials	Area/Weight m2/kg	Technical Notes
Standard	40-100 Model 60-150 Model 140-40 Model 40-100 Model 40-100 Model 40-100 Model 40-100 Model	0.1x0.4 0.1x0.4 0.1x0.4 0.27 0.1x0.4 0.25 0.2	stainless steel wire stainless steel wire stainless steel wire gal. iron wire copper wire polyamide fiber PVC fiber	1/0.5 " " 1/0.7	1, For 40-100 model: 40 holes in 100% width 2, Metal Filter mesh can be processed into weaves type
High Efficience Model	60-100 Model 80-100 Model 90-150 Model 200-400 Model 60-100 Model 80-100 Model	¢.012 0.1x0.3 0.1x0.3 0.1x0.3 0.1x0.3 ¢0.1-0.15 0.1-0.15	stainless steel wire stainless steel wire stainless steel wire stainless steel wire polyamide fiber polyamide fiber	1/0.6 1/0.6 1/0.6 1/0.6
High Permeability Model	30-100 Model 30-150 Model 70-400 Model	0.1x0.4 0.1x0.4 0.1x0.4	stainless steel wire stainless steel wire stainless steel wire stainless steel wire	1/0.4 1/0.4 1/0.4

gas liquid filter mesh/gas liquid filter netting/gas liquid filter nets/vapor-liquid filter mesh

Material:Stainless Steel Wire (AISI 201,202,301,304,304L,321,316, etc), Galvanized wire, Red

copper wire, ni wire,nylon wire and so on.

Wire Diameter: 0.1--0.55mm(usually use0.20-0.29mm)

Hole Size: 2x3mm--4x5mm--12x6mm

Width:0.1-1.22m

Characteristic:

1 Good penetration,corrosion resistance

2 High temperature resistance, flexible, good elasticity

3 high mechanical damping characteristics,provide ample protection from dynamic over loads

Q/SG12-1-79 steam fluid strainer standard specification model
Pattern	Specification
Standard type	40-100 60-150 105-300 140-400
Highly effective	60-100 80-100 80-150 90-150
Highly effective	150-300 200-400
Gao Chuanxing	20-100 30-150 70-400 100-600 170-560
Gao Chuanxing	33-30 38-40 20-40 26-40 30-40
Damping	30-50 48-50 30-60 30-80 50-120

Q/SG12-88-91 steam fluid strainer standard specification model
Pattern	Specification
Standard type	40-100 60-150 105-300 140-400 160-400 200-570
Highly effective	60-100 80-100 80-150 90-150
Highly effective	150-300 200-400 300-600
Gao Chuanxing	20-100 30-150 70-400 100-600 170-560
Gao Chuanxing	33-30 38-40 20-40 26-40 30-40
Damping	30-50 48-50 30-60 30-80 50-120
